Yamaha XSR125…506,000 yen
Yamaha Motor will release the 2025 model of its neo-retro style moped, the XSR125 ABS, on April 16th. The manufacturer’s suggested retail price is 506,000 yen (tax included).
Retro-inspired design
The XSR125 ABS incorporates retro design elements such as a round LED headlight, teardrop-shaped fuel tank, and tuck-roll seat, while also being equipped with modern features.
The 2025 model will be available in two new colors: “Light Bluish Gray Metallic 9 (Silver)” and “Very Dark Orange Metallic 1 (Brown).” Together with the existing “Black Metallic 12 (Black),” this brings the total to three colors.
Engine with variable valve timing mechanism
The engine is a 124cc water-cooled, 4-stroke, SOHC, 4-valve, single-cylinder engine that produces a maximum output of 11kW (15PS) at 10,000rpm and a maximum torque of 12N・m at 8,000rpm. It employs a variable valve timing mechanism (VVA) to achieve both ease of handling at low and medium speeds and powerful driving performance at high speeds. It also features an assist and slipper clutch (A&S clutch) that reduces clutch operation and improves vehicle stability when downshifting.
Full-scale specifications such as inverted forks
The body is made of steel Deltabox frame, achieving both rigidity and light weight. The front is equipped with a Φ37mm inverted fork and the rear is equipped with a monoshock suspension, achieving a comfortable ride and high driving stability. The brakes are disc brakes on both the front and rear, and ABS is standard equipment. The tire sizes are 110/70-17 in the front and 140/70-17 in the rear, designed for on-road riding.
High fuel efficiency of approximately 50km/L
The overall length is 2,030 mm, the overall width is 805 mm, the overall height is 1,075 mm, the seat height is 810 mm, and the vehicle weight is 137 kg. The fuel tank capacity is 10 L, and the fuel consumption rate in WMTC mode is 49.4 km/L (with one occupant).
The XSR125 ABS is a model that combines retro design with the latest technology, and is expected to be a bike that can be used in a wide range of situations, from commuting in urban areas to weekend touring.
Main specifications
Certified model/engine stamped model: 8BJ-RE46J/E34LE
Overall length/width/height: 2,030mm/805mm/1,075mm
Seat height: 810mm
Wheelbase: 1,325mm
Ground clearance: 170mm
Vehicle weight: 137kg
Fuel consumption rate: Value reported by the Ministry of Land, Infrastructure, Transport and Tourism
Constant fuel consumption value: 60.3km/L (60km/h) WMTC mode value with two occupants
: 49.4km/L (Class 2) Subclass 2-2) (Single occupant)
Engine type: Water-cooled, 4-stroke, SOHC, 4-valve
Cylinder arrangement: Single-cylinder
Total displacement: 124 cm3
Bore x stroke: 52.0 mm x 58.7 mm
Compression ratio: 11.2:1
Maximum power: 11 kW (15 PS) / 10,000 rpm
Maximum torque: 12 N・m (1.2 kgf・m) / 8,000 rpm
Starting method: Self-acting
Lubrication method: Wet sump
Engine oil capacity: 1.05 L
Fuel tank capacity: 10 L (regular unleaded gasoline required)
Intake/fuel system/fuel supply system: Fuel injection
Ignition method: TCI (transistorized)
Battery capacity/type: 12 V, 3.0 Ah (10 HR) / YTZ4V
Primary/secondary reduction ratios: 3.041 (73/24) / 3.714 (52/14)
Clutch type: Wet Multi-plate
transmission / Transmission method: Constant mesh 6-speed / Return type
Gear ratio: 1st gear: 2.833, 2nd gear: 1.875, 3rd gear: 1.363, 4th gear: 1.142, 5th gear
0.956 6-speed: 0.840
Frame type: Diamond
caster / Trail: 25°30′ / 88mm
Tire size (front / rear): 110/70-17M/C (54S) (tubeless) / 140/70-17M/C (66S) (tubeless)
Braking system type (front / rear): Hydraulic single disc brake / Hydraulic single disc brake
Suspension system (front / rear): Telescopic / Swing arm (link type)
Headlamp bulb type / Headlamp: LED
Passenger capacity: 2 people
